Sealing robot

Particular attention to the containment of production, management and maintenance costs.
Easy to connect to many existing lines.

Description

Automatic sealing robot for the last sealing of rectangular, shaped double and triple glazed unit.

With high efficiency & stable quality sealing performance this robot is economical, practical, designed for all glassworks that want toautomate the process of sealing of the insulating glass, reducing labor intensity, saving manpower
and improving production efficiency.
Compatible with many of the existing plants, or also suitable for processing off-line, ensure a considerablereduction of production times associated with a higher precision of sealing, eliminating waste of time and material.

Designed and manufactured entirely in Italy in our factory, it allows a wide range of modifications and customizations to satisfy the specifications of each customer.

Equipped with Mitsubishi’s electronics parts and with components made in Italy guarantees rreliability, stable performance, easy use and maintenance.

TECHNICAL FEATURES

Srm1600

Srm1600

Srm 2000

Srm 2500

Max. Glass Size

3000x1600

3000x2000

3000x2500

Panel Thickness

12-52mm

12-52mm

12-52mm

Sealing Width

4-30mm

4-30mm

4-30mm

Sealing Depth

2-9mm

2-9mm

2-9mm

Speed

0-18 mt /min

0-18 mt /min

0-18 mt /min

Carico massimo

300 kg

300 kg

300 kg

GUARDALA IN FUNZIONE

Puoi trovare altri video delle nostre macchine in funzione sul canale YouTube. Seguici!
